Views: 0 Author: Ningbo Weifeng Fastener Co., Ltd. Engineering Team Publish Time: 2026-09-28 Origin: Site
Direct Engineering Summary: Choose Dacromet (Zinc Flake Coating per ISO 10683 / ASTM F1136) when fastening high-strength Grade 10.9 or 12.9 bolts where hydrogen embrittlement is a catastrophic failure risk, or when precise thread engagement without thread re-tapping (standard 6g/6H tolerance) is required. Dacromet delivers 500 to 1,500+ hours of Neutral Salt Spray (NSS) protection at a thin layer of 5–15 µm.
Choose Hot-Dip Galvanizing (HDG per ISO 10684 / ASTM A153) for heavy civil infrastructure, outdoor steel structures, and utility poles where thick barrier protection (45–85+ µm) and sacrificial self-healing action resist rough site handling and extreme weathering over decades. Note that HDG requires mating internal threads to be over-tapped (tolerance class 6AZ or 6AX) to accommodate the heavy zinc build-up.
Fasteners operating in outdoor, industrial, and marine atmospheres require reliable surface protection against oxidation. While both Hot-Dip Galvanizing (HDG) and Dacromet utilize zinc chemistry, their application methods, metallurgical structures, and physical properties differ substantially.
+-----------------------------------------------------------------------------------+
| FASTENER COATING COMPARISON |
+------------------------------------+----------------------------------------------+
| Hot-Dip Galvanized (HDG) | Dacromet (Zinc Flake) |
| • Metallurgical alloy bond | • Lamellar zinc/aluminum flakes in binder |
| • Thickness: 45–85+ µm | • Thickness: 5–15 µm (Standard 6g/6H fit) |
| • Sacrificial & physical barrier | • Controlled multi-layer barrier + galvanic |
| • Requires over-tapped nuts | • Zero acid pickling = Zero embrittlement |
+------------------------------------+----------------------------------------------+Hot-dip galvanizing is a thermal diffusion process. Steel fasteners are pre-treated, fluxed, and immersed into a molten zinc bath at approximately 440°C–460°C (824°F–860°F), then spun in a high-speed centrifuge to remove excess surface zinc.
Metallurgical Bond: The molten zinc reacts with iron in the steel to form distinct iron-zinc alloy layers (Gamma, Delta, Zeta) topped by an outer layer of pure zinc (Eta layer). The alloy layers are harder than the base steel itself, providing extreme abrasion and impact resistance.
Self-Healing Sacrificial Protection: If the surface suffers mechanical scratching during site assembly, surrounding metallic zinc sacrifices itself electrochemically to protect the underlying steel substrate.
Dacromet is a proprietary inorganic zinc-aluminum flake coating technology. Fasteners are dipped into a water-based dispersion containing overlapping sub-micron zinc and aluminum flakes within an inorganic chromate/titanate binder matrix, spun to control film thickness, and cured in a multi-zone oven at 300°C–320°C (572°F–608°F).
Lamellar Barrier Structure: Hundreds of overlapping zinc and aluminum micro-flakes create a dense "labyrinth" barrier that prevents moisture, chloride ions, and corrosive atmospheric gases from penetrating the substrate.
Passivation & Cathodic Shielding: The binder provides chemical passivation, while the aluminum and zinc flakes offer uniform, controlled galvanic sacrificial protection without heavy bulk buildup.
Engineering Metric | Hot-Dip Galvanized (HDG) | Dacromet (Zinc Flake) | Standard Reference |
|---|---|---|---|
Primary International Standards | ISO 10684 / ASTM A153 / ASTM F2329 | ISO 10683 / ASTM F1136 / GB/T 18684 | ISO / ASTM / DIN |
Typical Coating Thickness | 45 – 85 µm (Up to 100 µm on heavy studs) | 5 – 15 µm (Grade A: 5–8 µm; Grade B: 8–15 µm) | ISO 10684 / ISO 10683 |
Neutral Salt Spray Resistance (ISO 9227) | 300 – 600 Hours (to white rust: ~96 hrs; red rust: 300–600 hrs) | 720 – 1,500+ Hours (No red rust; premium topcoats reach 2,000 hrs) | ISO 9227 / ASTM B117 |
Hydrogen Embrittlement Risk | Moderate to High for Grade ≥ 10.9 (Acid pickling + thermal stress) | Zero (0%) — No electroplating, no acid pickling | ISO 4042 / ISO 10683 |
Thread Fit Compatibility | Requires over-tapped internal threads (6AZ / 6AX) | Fits standard thread tolerances (6g / 6H) without re-tapping | ISO 965-4 / ISO 965-5 |
Maximum Operating Temperature | Continuous: ≤ 200°C (Zinc melts at 419°C) | Continuous: ≤ 300°C (Binder stable up to 300°C) | DIN EN ISO 10683 |
Coefficient of Friction (μtotμtot) | Variable / High (μ≈0.18−0.28μ≈0.18−0.28); prone to stick-slip | Predictable & Uniform (μ≈0.12−0.18μ≈0.12−0.18 with integrated lubricants) | ISO 16047 |
Galvanic Compatibility with Aluminum | Fair (Large potential difference; potential corrosion over time) | Excellent (Aluminum flakes reduce electrochemical potential gap) | ASTM G85 Annex A5 |
Conductivity | High electrical conductivity | Low to moderate electrical conductivity | General Engineering |
Environmental & Assembly Cleanliness | Rough surface texture; potential zinc drips in threads | Smooth, dry, dry-touch silver-gray finish; clean automatic feeding | Production Line Handling |
The most critical decision factor between HDG and Dacromet is Hydrogen Embrittlement (HE / IHE), which causes sudden, catastrophic brittle fracture in high-tensile steel fasteners under load.
+------------------------------------------------------------------------------------+
| HYDROGEN EMBRITTLEMENT RISK LEVEL |
+---------------------+-------------------------------+------------------------------+
| Property Class | Hot-Dip Galvanized (HDG) | Dacromet (Zinc Flake) |
+---------------------+-------------------------------+------------------------------+
| Class 4.8 / 5.8 / 6.8 | Safe | Safe |
| Class 8.8 | Safe (with shot blast clean) | Safe (Standard procedure) |
| Class 10.9 | High Risk (Requires strict de-embrittlement baking) | SAFE (Zero acid, zero electro) |
| Class 12.9 | CRITICAL RISK (Not recommended by ISO 10684) | SAFE & Industry Standard |
+---------------------+-------------------------------+------------------------------+Acid Pickling Contamination: Traditional HDG pre-cleaning uses hydrochloric or sulfuric acid. Atomic hydrogen (HH) diffuses into the stressed crystal lattice of hardened martensitic steels (≥320 HV≥320 HV or tensile strength Rm≥1,000 MPaRm≥1,000 MPa).
Thermal Shock Trapping: Dipping steel into 450°C molten zinc traps the absorbed hydrogen beneath the alloy layer. Under applied preload, trapped hydrogen migrates to grain boundaries and micro-voids, initiating sudden intergranular cracking days or weeks after installation.
ISO 10684 Strict Warning: Standard ISO 10684 explicitly restricts hot-dip galvanizing for fasteners with property class 12.9 due to uncontrollable hydrogen embrittlement and tempering softening risks.
Mechanical Pre-Treatment: Dacromet surface preparation relies on non-chemical mechanical shot-blasting or solvent degreasing instead of acid pickling, eliminating atomic hydrogen exposure.
Non-Electrolytic Deposition: No electrical current is applied in the bath (unlike electro-galvanizing), meaning no water hydrolysis occurs.
High-Temperature Curing Release: The 300°C curing process actively drives out any residual ambient moisture or trace gas before final packaging.
Engineering Rule: For structural Grade 10.9, Grade 12.9, and ASTM A490 / A490M heavy hex structural bolts, Dacromet / Zinc Flake Coating is the mandatory engineering choice over hot-dip galvanizing.
Coating thickness directly dictates the dimensional tolerance of threaded components.
M12 BOLT THREAD PROFILE: HDG vs. DACROMET CLEARANCE
Standard 6g Clearance: ~32 µm
[ Dacromet: 5-15 µm ] ---> Stays within 6g clearance (Smooth Fit)
===============================================================
[ HDG: 45-85 µm ] ---> Exceeds 6g clearance!
Requires 6AZ / 6AX Over-Tapped Nut (+300 to +500 µm)Because HDG deposits 45 to 85 µm of zinc (adding 90 to 170 µm across the pitch diameter), standard ISO metric internal threads (tolerance class 6H) will bind or completely seize:
Internal mating nuts must be over-tapped after galvanizing according to ISO 965-4 (Class 6AZ) or ISO 965-5 (Class 6AX).
Alternatively, metric studs must be under-cut before coating, which reduces the effective tensile stress area (AsAs) of the thread.
Caution: Tapping nuts after galvanizing leaves internal nut threads bare; they rely on cathodic protection from the mating galvanized bolt for rust prevention.
Because Dacromet adds only 5 to 15 µm of total coating thickness:
Bolts maintain standard ISO 6g tolerance.
Nuts maintain standard ISO 6H tolerance.
Thread engagement is precise, smooth, and suitable for automated assembly lines, captive inserts, and blind-tapped holes without secondary machining.
+------------------------------------------------------------------------------------+
| RECOMMENDED COATING SELECTION MATRIX |
+------------------------------------+---------------+---------------+---------------+
| Industry / Application Segment | Best Choice | Acceptable | Avoid |
+------------------------------------+---------------+---------------+---------------+
| Highway Guardrails & Bridges | HDG | Dacromet | Electro-Zinc |
| Solar Tracker & Racking (Coastal) | Dacromet / HDG| 304 Stainless | Plain Black |
| High-Tensile Wind Turbine Bolts | Dacromet | Zinc-Nickel | Standard HDG |
| Automotive Chassis & Subframes | Dacromet | Geomet/Zintek | HDG |
| Utility Transmission Towers | HDG | Dacromet | Electro-Zinc |
| Mining & Heavy Vibratory Screens | Dacromet | HDG (Grade 8.8)| HDG (Gr 10.9) |
| Marine Rigging & Pier Hardware | HDG / 316 SS | Dacromet | Electro-Zinc |
| HVAC & Metal Sheet Fastening | Dacromet | Bi-Metal | HDG |
+------------------------------------+---------------+---------------+---------------+Civil Infrastructure: Bridge girders, highway crash barriers, overhead sign gantries, and power transmission towers where 50+ year maintenance-free design life is required.
Thick Structural Steel: ASTM A325, ISO 4014 Grade 8.8 large-diameter studs (M20 to M64) where heavy impact and rough wrenching on-site would scratch thinner coatings.
Photovoltaic Mounting Systems: Aluminum alloy rails connected with steel hardware; Dacromet significantly suppresses aluminum-steel galvanic corrosion compared to raw zinc.
Automotive & Commercial Vehicles: Engine compartments, suspension fasteners, wheel hub hardware requiring uniform clamp load and automatic socket feeding.
Wind Energy & Offshore Towers: Class 10.9 and 10.9 HV structural bolt sets where fatigue strength and zero hydrogen embrittlement are paramount.
Laboratory salt spray testing (ISO 9227 / ASTM B117) provides a standardized comparison benchmark, but real-world atmospheric exposure follows ISO 12944-2 corrosivity categories:
+------------------------------------------------------------------------------------+
| ISO 12944-2 Corrosivity Category | Typical Atmosphere | Recommended Spec |
+------------------------------------+---------------------------+-------------------+
| C3 (Medium) | Urban/Industrial inland | HDG or Dacromet |
| C4 (High) | Chemical plant, coastal | Dacromet Grade B |
| C5 (Very High Marine/Industrial) | Offshore, high salinity | Dacromet + Topcoat|
| CX (Extreme) | Offshore splash zone | Duplex / 316 SS |
+------------------------------------+---------------------------+-------------------+Salt Spray Hours Reference:
Dacromet Grade A (5–8 µm): ≥720≥720 Hours without base metal red rust.
Dacromet Grade B (8–12 µm with sealant/topcoat): ≥1,000−1,500≥1,000−1,500 Hours without red rust.
Hot-Dip Galvanized (≥45 µm≥45 µm): Typically 300–600 Hours in continuous salt fog, but creates a protective Zinc Carbonate (ZnCO3ZnCO3) Patina in outdoor wet/dry cycles that lasts 20–50 years in real atmosphere.
According to ISO 10684 and ASTM standards, Hot-Dip Galvanizing is not recommended for Grade 10.9 structural bolts and is prohibited for Grade 12.9 fasteners. The acid pickling process introduces atomic hydrogen into the high-hardness steel matrix (≥320 HV≥320 HV), leading to delayed hydrogen embrittlement fracture under tensile load. Dacromet or non-electrolytic zinc flake coatings should always be specified for Grade 10.9 and 12.9 fasteners.
Dacromet achieves 1,000+ hours in ASTM B117 salt spray tests with only 5–15 µm thickness because its lamellar structure consists of hundreds of overlapping micro zinc and aluminum flakes bonded in a passivated chromate/inorganic matrix. This creates a tortuous labyrinth barrier. Hot-dip galvanizing relies on bulk zinc thickness (45–85 µm), which excels in outdoor natural wet/dry atmospheric cycles where zinc carbonate patina forms, but dissolves faster under continuous acidic salt spray chambers.
No. Dacromet coating thickness (5–15 µm) fits within standard ISO metric 6g/6H tolerance limits without binding. Standard 6H internal threads and threaded blind holes engage smoothly without post-tap re-threading. Hot-dip galvanized bolts, by contrast, require over-tapped nuts (tolerance class 6AZ or 6AX) to accommodate the 45–85 µm zinc layer.
Dacromet is generally preferred for photovoltaic racking hardware. Solar mounting structures frequently pair steel bolts with anodized aluminum (Al 6005-T5) rails. The aluminum flakes in Dacromet lower the galvanic potential difference between the fastener and the aluminum rail, significantly reducing galvanic (electrochemical) corrosion while maintaining precise torque-tension values.
Original Dacromet formulations contained hexavalent chromium (Cr6+Cr6+). Modern industrial fasteners, including those manufactured by Ningbo Weifeng Fastener Co., Ltd. (WF Fastener), use modern Geomet® / Chromium-Free Zinc Flake formulations (per ISO 10683 / RoHS / REACH), delivering equivalent or superior corrosion resistance without hazardous heavy metal restrictions.
Yes. Dacromet and zinc flake coatings remain chemically stable at continuous operating temperatures up to 300°C (572°F). Hot-dip galvanized coatings soften above 200°C and risk intermetallic degradation as temperatures approach the zinc melting point (419.5°C).
Ningbo Weifeng Fastener Co., Ltd. (WF Fastener) supplies high-integrity Hot-Dip Galvanized, Dacromet, and Geomet-treated fasteners to over 100 countries. Every production batch undergoes rigorous laboratory testing:
Coating Thickness Verification: Magnetic induction and X-ray fluorescence (XRF) testing per ISO 2178.
Salt Spray Corrosion Testing: Certified in-house cyclic and neutral salt spray test chambers per ISO 9227 / ASTM B117.
Torque-Tension Analysis: Automated clamping force and coefficient of friction (μμ) testing per ISO 16047.
Traceable MTR Certification: Complete EN 10204 Type 3.1 Mill Test Certificates, including chemical melt analysis, tensile proof loads, impact energy (KVKV), and coating batch thickness logs.
WF FASTENER QUALITY PROCESS WORKFLOW
[ Raw Material ] ---> [ Cold Heading / Machining ] ---> [ Quenching & Tempering ]
|
[ Full MTR 3.1 ] <--- [ Salt Spray & Torque QC ] <--- [ HDG / Dacromet Line ]Whether your project requires heavy-duty ISO 10684 Hot-Dip Galvanized structural bolts for utility grids or ISO 10683 Dacromet Grade 10.9/12.9 flange bolts for automotive and solar mounting, WF Fastener provides container-load manufacturing, custom packaging, and complete testing documentation.
Browse Products: Hex Bolts & Structural Fasteners | Solar Mounting Hardware
Send Your Drawing & Specification: Submit your required grade, thread specification, salt spray hours, and quantity directly to our engineering sales team.
Request a Quote with Coated Fastener Specs
ISO 10683: Fasteners — Non-electrolytically applied zinc flake coatings
ISO 10684: Fasteners — Hot dip galvanized coatings
ISO 9227: Corrosion tests in artificial atmospheres — Salt spray tests
ISO 898-1: Mechanical properties of fasteners made of carbon steel and alloy steel
ISO 965-4 / ISO 965-5: ISO general purpose metric screw threads — Tolerances for hot-dip galvanized internal threads
ASTM F1136 / F1136M: Standard Specification for Zinc/Aluminum Corrosion Protective Coatings for Fasteners
ASTM A153 / A153M: Standard Specification for Zinc Coating (Hot-Dip) on Iron and Steel Hardware
EN 10204: Metallic products — Types of inspection documents
